全系列微电机解决方案
| Winding Type | Star |
| Hall Effect angle | 120° electrical angle |
| Insulation Class | B |
| Ambient Temperature Range | -20℃~+50℃ |
| Insulation Resistance | 100MΩ Min.500V DC |
| Dielectric Strength | 1500VAC 1minute |
| Model电机型号 | - | 105BLY01A |
| Number of Poles极数 | - | 4 |
| Number of Phases相数 | - | 3 |
| Rated Voltage额定电压 | VDC | 310 |
| Rated speed额定转速 | RPM | 4000 |
| Rated Torque额定力矩 | N-m | 0.22 |
| Rated Current额定电流 | Amps | 0.5 |
| Output Power输出功率 | Watts | 92 |
| Peak Torque峰值力矩 | N-m | 0.66 |
| Peak Current峰值电流 | Amps | 1.5 |
| Torqueconstant力矩常数 | N-m/Amps | 0.51 |
| Back EMF反电势常数 | V/kRPM | 53.5 |
| Rotor inertia转动惯量 | g・cm² | 1000 |
| Body Length (L)机身长度 | mm | 81.5 |
| Mass重量 | kg | 2.4 |
Caution 1: Peak Torque is provided for the purpose of performance calculations only. Operate near or at thiscondition will result inmotordamaged.峰值力矩仅作为参数参考，接近或在此条件下长时间使用，将导致电机损坏Note: We can also manufacture products according to customer's requirements. 以上为代表产品, 派生
品可根据客户要求制作
