| 外壳材质 | Housing Material | 粉末冶金 |
| 输出轴承形式 | Bearing at output | 滚珠轴承 |
| 径向负载 | Radial load (10mm from flange) | ≤250(N) |
| 轴向负载 | Shaft axial load | ≤100(N) |
| 静态主轴最大承受压入力 | Shaft press fit force max Static | ≤1000(N) |
| 径向间隙 | Radial play of shaft | ≤0.08(mm) |
| 轴向间隙 | Thrust play of shaft | ≤0.5(mm) |
| 背隙（无负载时） | Backlash at no-load | ≤2.5° |
*负载与转速有关，具体数据需参考实际情况。
*Load relates to speed, actual value depends on different situation.
| 减速比 | 额定允许负载（Nm） | 瞬间允许负载（Nm） | 效率（%） | 长度（mm） | 重量（g） | 减速比级数 |
|---|---|---|---|---|---|---|
| 1:3.6 | 10 | 30 | 90% | 48 | 430 | 1 |
| 1:4.25 | 10 | 30 | 90% | 48 | 430 | 1 |
| 1:5.33 | 10 | 30 | 90% | 48 | 430 | 1 |
| 1:12.96 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:15.3 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:18.06 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:19.2 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:22.67 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:28.44 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:46.66 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:55.08 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:65.03 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:69.12 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:76.77 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:81.6 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:96.33 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:102.4 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:120.89 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:151.70 | 40 | 70 | 72% | 72 | 710 | 3 |
