| 外壳材质 | Housing Material | 粉末冶金 |
| 输出轴承形式 | Bearing at output | 含油轴承 |
| 径向负载 | Radial load (10mm from flange) | ≤35(N) |
| 轴向负载 | Shaft axial load | ≤15(N) |
| 静态主轴最大承受压入力 | Shaft press fit force max Static | ≤80(N) |
| 径向间隙 | Radial play of shaft | ≤0.08(mm) |
| 轴向间隙 | Thrust play of shaft | ≤0.4(mm) |
| 背隙（无负载时） | Backlash at no-load | ≤1.5° |
*负载与转速有关，具体数据需参考实际情况。
*Load relates to speed, actual value depends on different situation.
| 减速比 | 额定允许负载（Nm） | 瞬间允许负载（Nm） | 效率（%） | 长度（mm） | 重量（g） | 减速比级数 |
|---|---|---|---|---|---|---|
| 1/4 | 0.1 | 0.3 | 81% | 13.9 | 29 | 1 |
| 1/4.75 | 0.1 | 0.3 | 81% | 13.9 | 29 | 1 |
| 1/16 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/19 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/22 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/26 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/64 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/76 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/88 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/104 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/121 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/144 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
